Why to choose data and computer cables from HELUKABEL?
Data cables are primarily used to transmit data and information accurately and stably from the sender to the receiver. The cable is designed to be sturdy with a special structure for data transmission function, used in network systems, especially in the fields of television transmission, security and surveillance systems.
One of the long-term partners of many industries in the production and supply of quality control cables, signal cables, and accessories is HELUKABEL from the Federal Republic of Germany.
With over 40 years in the market, HELUKABEL continues to research and develop to achieve even greater achievements in the future. We aim to find new solutions based on market trends and new technologies to provide quality products that meet customer needs.
With a portfolio of over 33,000 products and a team of experienced engineers and experts, we will help you analyze the project and select the appropriate products for each industry. In addition, we are also willing to listen to customer issues and requirements to research and produce corresponding electrical cable products suitable for each project.
Call +84 28 77755578 or email us at info@helukabel.com.vn or register for free consultation on specific control cable and signal cable types with specialized engineers by filling out the form.
Contact our HELUKABEL Vietnam engineers to get a quote & expert consultation
HELUKABEL data cable catalog
1. Data cables
Discover our products
2. Halogen-free data cables
Discover our products
3. UL/CSA-approved data cables
Discover our products
4. Drag chain data cables
Discover our products
5. Instrumentation cables
Discover our products
6. Computer data cables
Discover our products
7. Data cables for Industrial Electronics
Discover our products
8. Compensating cables
Discover our products
9. Ribbon cables
Discover our productsOutstanding features of HELUKABEL's data cables
1. PAAR-TRONIC-CY data cable
Function to transmit data from the source to the output device, transmit information between multiple computers, so data cables play an important role in any computer system, especially in management computer systems in manufacturing plants.
Besides, some halogen-free data cable is suitable for buildings or projects with high population density such as office buildings, apartment buildings, transportation systems, and industrial plants. Halogen-free cable does not produce toxic smoke in the event of a fire, which helps to minimize harm to human health and protect valuable assets.
2. HELUDATA® EN-50288-7 XLPE/PVC OS 500 instrumentation cable
The instrumentation cables are used wherever processes need to be controlled and monitored: they transmit measurement data on temperature, pressure or flow rate, for example, and are used to control valves, temperature regulators and pilot lamps. Especially in onshore plants such as refineries or chemical plants, the distances between the control room and the component to be controlled (such as a valve, control lamp or sensor) can be very long. To ensure error-free transmission of signals over these long distances, our instrumentation cables are ideal.
Features of PAAR-TRONIC-CY data cables
- Twisted pair
- Copper conductor acc. to DIN VDE 0295, Class 5 và IEC 60228, Class 5
- PVC outer sheath
- Temperature range: -5°C to 80°C (flexing), -30°C to 80°C (fixed installation)
- Screen: braided screen of tinned copper wires, approx. coverage 85%
- Suitable for flexible applications with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms. Used as control and signal cables for systems at risk of interference radiation.
Datasheet of PAAR-TRONIC-CY data cable
Features of HELUDATA® EN-50288-7 XLPE/PVC OS 500 cable
- Bare copper acc. to DIN VDE 0295 cl.2, IEC 60228 cl.2
- Cores stranded in pairs, triads or quads
- Temperature range: -5°C to 50°C (flexing), -30°C to +90°C (fixed installation)
- For the transmission of digital and analog signals in harsh environments like oil, gas and petrochemical industries. The cables are suitable for fixed installation in dry and damp locations, open spaces and in underground networks.
Datasheet of HELUDATA® EN-50288-7 XLPE/PVC OS 500 cable
3. PAAR-TRONIC-Li-2YCYv data cable
PE-insulated data cable with twisted pairs, for interference-free transmission of data and signals over longer distances. The twisted-pair lay-up prevents electrical unbalances within the cable and this thus effectively suppresses cross-talking effects.
The high transmission rates are particularly suitable for RS 422 and RS 485 interfaces; suitable for fixed installations in dry, damp and wet rooms, as well as outdoors and direct burial.
4. SUPER-PAAR-TRONIC-340-C-PUR data cable
Drag chain compatible cable with overall screen and stranded in pairs that offers operational possibilities where outer electrical influences at high frequence may cause interference of impulse transmission.
This highly flexible data cable with enhanced sliding capabilities by using PP-core insulation and an adhesion-low and cut-resistant PUR-outer sheath, guarantees optimum durability and is highly economic.
Features of PAAR-TRONIC-CY data cables
- Twisted pair
- Copper conductor acc. to DIN VDE 0295, Class 5 và IEC 60228, Class 5
- PVC outer sheath
- Temperature range: -5°C to 80°C (flexing), -30°C to 80°C (fixed installation)
- Screen: braided screen of tinned copper wires, approx. coverage 85%
- Suitable for flexible applications with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms. Used as control and signal cables for systems at risk of interference radiation.
Datasheet of PAAR-TRONIC-CY data cable
Đặc điểm của cáp SUPER-PAAR-TRONIC-C-PUR®
- Copper wire bare acc. to DIN VDE 0295 cl.2, IEC 60228 cl.2
- PP insulation, outer sheath is made from speacial PUR (compund type TMPU)
- Temperature range: -30°C to 70°C (flexing), -40°C to +70°C (fixed installation)
- Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion
- Halogen-free
Datasheet of SUPER-PAAR-TRONIC-C-PUR®
Order Now on HELUKABEL E-Store – Fast & Easy!
Data cables
Analog data cables offer a reliable solution for interference-free transmission of control and signal information in industrial applications. They are primarily used in mechanical engineering and automation technology—both for fixed installations and for continuous motion applications. Their design provides excellent electrical insulation and, depending on the version, effective EMC protection against electromagnetic interference. This makes data cables a proven and cost-effective choice for secure and precise signal transmission in demanding industrial environments.
| Data cable | Sheath material | Number of cores | Cross-sectional area (mm²) | Characteristics | Part number |
| TRONIC-CY (LiY-CY) | PVC | 1 - 61 | 0.14 - 1.5 | Extremely small outer-Ø, suitable for electronic devices | 20139 |
| PAAR-TRONIC-Li-2YCYv | Polyvinyl chloride | 4 - 20 | 0.22 - 1 | UV resistant, RS422 and RS485 compatible | 21129 |
| PAAR-TRONIC-Li-2YCY | PVC | 4 - 20 | 0.22 - 0.5 | RS422 and RS485 compatible | 21111 |
| DATAPUR-C® | Special polyurethane | 2 - 25 | 0.14 - 0.5 | Robust, notch-resistant data cable for high mechanical stress | 52490 |
| EDV-PiMF-CY | PVC | 4 - 100 | 0.5 - 1.5 | Eca CPR | 43553 |
| LifYCY | PVC | 4 - 64 | 0.2 | Highly flexible in handling and installation, UKCA | 15987 |
| LiY-TPC-Y | PVC | 4 - 20 | 0.25 - 1 | Cable for sound mixers, studio equipment, and measurement and control technology | 21323 |
| PAAR-TRONIC-CY | PVC | 2 - 122 | 0.14 - 1.5 | Eca CPR | 21001 |
Halogen-free data cables
Halogen-free data cables are the ideal solution for the safe transmission of control and signal information in industrial applications where there are high fire protection requirements and low smoke emission standards.
They are primarily used in mechanical engineering, automation technology, and buildings with increased safety standards. Halogen-free insulation and sheathing materials prevent the formation of corrosive and toxic gases in the event of a fire.
| Halogen-free cables | Sheath material | Number of cores | Cross-sectional area (mm²) | Characteristics | Part number |
| DATAFLAMM®-C | Thermoplastic | 2 - 40 | 0.14 - 0.75 | Low capacitance, CPR class (Eca, Fca) | 52365 |
| DATAFLAMM®-C-PAIR | Thermoplastic | 4 - 36 | 0.14 - 0.75 | Low capacitance | 52435 |
| JE-LiHCH Bd | Halogen-free | 4 - 80 | 0.5 | Cables for Industrial Electronics | 34350 |
| HELUDATA® ROBOFLEX®-PAIR-D PUR UL/CSA | PUR | 6 - 20 | 0.14 - 0.5 | UL/CSA, UV resistant, torsion resistant | 11022463 |
| MULTISPEED®-TRONIC-PUR | PUR | 2 - 25 | 0.25 - 0.34 | Oil-resistant, highly wear-resistant | 24567 |
UL/CSA data cables
UL/CSA-approved data cables are the ideal choice for applications requiring compliance with international safety and quality standards. They are primarily used in industry, mechanical engineering, and automation technology—both for fixed installations and continuous motion applications.
Thanks to their UL and CSA certification, these cables guarantee standard-compliant signal transmission and meet the requirements for use in North American markets.
| UL/CSA data cables | Sheath material | Number of cores | AWG | Characteristics | Part number |
| HELUDATA® 2919 PE/PVC-TP-C 30 GREY | PVC | 2 - 4 | 24 | UL Style 2919, 30 V, 80°C | 11005140 |
| HELUDATA® 20276 PE/PVC-TP 30 GREY | PVC | 4 - 8 | 22 | UL Style 20276, 30 V, 60°C | 11000630 |
| HELUDATA® 2092 PE/PVC-TP 300 GREY | PVC | 2 | 16 -22 | UL Style 2092, 300 V, 60°C | 11000611 |
| HELUDATA® 2094 PE/PVC-TP 300 GREY | PVC | 2 - 12 | 18 - 22 | UL Style 2094, 300 V, 60°C | 18024870 |
| HELUDATA® 2464 PVC/PVC-TP 300 | PVC | 1 | 16 | UL Style 2464, 300 V, 80°C | 11000620 |
| TRAYCONTROL® 300 | Special PVC | 2 - 50 | 16 - 28 | Oil Res I/II, exposed run: PLTC-ER, ITC-ER, CM, CMG, NFPA 79 | 62625 |
| TRAYCONTROL® 300 TP | 1 - 25 | 18 - 26 | 62794 | ||
| TRAYCONTROL® 300-C | 2 - 50 | 16 - 18 | 62710 | ||
| TRAYCONTROL® 300-C TP | 2 - 50 | 18 - 26 | 61999 |
Instrument and computer data cables
Instrumentation cables and computer cables are the ideal solution for accurately transmitting measurement, control, and signal information in industrial applications. They are primarily used in process and automation technology, where high signal quality and immunity to interference are crucial. Thanks to their special design, these cables offer reliable electrical insulation and, depending on the version, effective shielding for EMC protection against electromagnetic interference. This makes instrumentation and computer cables a proven choice for safe and interference-free signal transmission in complex industrial plants.
| Instrument cable | Sheath material | Number of cores | AWG | Characteristics | Part number |
| HELUDATA® PLTC UL13 PVC/PVC OS 300 | PVC | 2 - 72 | 14 - 18 | UKCA | 11014702 |
| HELUDATA® PLTC UL13 XLPE/LS0H OS 300 | LS0H | 2 - 72 | 14 - 18 | UKCA, XLPE/OS/LS0H | 11018400 |
| HELUDATA® EN-50288-7 Fire Resistant OSA 500 | LS0H | 2 - 25 | 12 - 16 | Halogen-free, XLPE/OS/SWA/LS0H | 11016406 |
| HELUDATA® EN-50288-7 XLPE/PVC IOSA 500 | PVC | 4 - 72 | 14 - 20 | XLPE/IS/OS/PVC/SWA/PVC | 11013113 |
| HELUDATA® PAS 5308 PE/PVC IAM/CAM/SWA | PVC | 2 - 36 | 14 - 20 | PE/PVC, individual and overall screen, armored | 11001070 |
| Computer cables | Sheath material | Number of cores | Cross-section | Characteristics | Part number |
| RE-2Y(St)Yv | PVC | 2 - 96 | 0.5 - 1.3 | reinforced outer sheath | 20099 |
| RD-Y(St)Y | PVC | 4 - 192 | 0.5 | Transmit analog and digital signals up to 10 kHz | 20140 |
| RE-2Y(St)Yv PiMF | PVC | 4 - 96 | 0.5 - 1.3 | reinforced outer sheath | 20115 |
| RD-H(St)H | PVC | 4 - 192 | 0.5 - 1 | UKCA, CPR (EC, DC) | 20200 |
| RD-Y(St)Yv | PVC | 4 - 192 | 0.5 | reinforced outer sheath | 20160 |
| RD-Y(St)YY | PVC | 4 - 192 | 0.5 | double outer sheath | 20180 |
Data cables for Industrial Electronics
Industrial electronics cables are the ideal solution for reliable transmission of control, measurement, and signal information in electronic and industrial applications. They are primarily used in automation technology, mechanical engineering, and process control, where high signal quality and operational reliability are essential.
Thanks to their specialized design, these cables provide excellent electrical insulation and, depending on the version, effective shielding for EMC protection against electromagnetic interference.
This makes industrial electronics cables a proven choice for precise and interference-free signal transmission in demanding industrial environments.
Ribbon data cables
Ribbon cables are the ideal solution for compact and clear connection of control and signal components in industrial applications. They are primarily used in automation technology, mechanical engineering, and electronic devices where space-saving and flexible cable routing is required.
Their flat design allows for easy installation and clear cable routing, even in complex systems. Depending on the design, ribbon cables offer reliable electrical insulation and, in shielded versions, effective EMC protection against electromagnetic interference.
