3 APPLICATIONS OF TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J CONTROL CABLE

3 applications of topflex®-emv-uv-3 plus 2yslcyk-j control cable

TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cables are applied in many manufacturing industries, such as environmental technology, packaging, and chemical industry, etc. A better understanding of the features and specifications of the TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable will help you make suitable choices for your project.

Technical data

Special motor power supply cable for frequency converters to Style 2570

  • Temperature range

flexing -5°C bis +80°C

fixed installation -40°C bis +80°C

  • Nominal voltage UL 1000 V
  • Test voltage 4000 V
  • Insulation resistance: min. 200 MOhm x km
  • Coupling resistance

acc. to a different cross-section

max. 250 Ohm/km

  • Minimum bending radius

fixed installation for outer Ø:

up to 12 mm: 5x cable Ø

> 12-20 mm: 7,5x cable Ø

> 20 mm: 10x cable Ø

free-movement for outer Ø:

up to 12 mm: 10x cable Ø

> 12-20 mm: 15x cable Ø

> 20 mm: 20x cable Ø

  • Radiation resistance

up to 80x106 cJ/kg (up to 80 Mrad)

Cable structure

  • Bare copper, fine wire conductor to DIN VDE 0295 cl.5, BS 6360 cl.5 and IEC 60228 cl.5
  • Core insulation of polyethylene (PE)
  • Core identification BK, BN, GY
  • GN-YE conductor (divided into 3)
  • Cores stranded in concentric layers
  • 3+3 core design
  • 1. Screen with special aluminum film
  • 2. Tinned copper braided screen, approx. 85% coverage
  • Outer sheath of special PVC
  • Sheath color black (RAL 9005)
  • with meter marking
TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable is used in industries such as automotive, motorcycle and food, environmental technology, packaging, and chemical industry.
TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable is used in industries such as automotive, motorcycle and food, environmental technology, packaging, and chemical industry.

Properties

  • Low mutual capacitance
  • Meets EMC requirements acc. to EN 55011 and DIN VDE 0875 part 11
  • Low coupling resistance for high electromagnetic compatibility
  • Due to the optimal screening, an interference-free operation of frequency converters is obtained
  • The 3 Plus-construction of motor power supply cables features a symmetrical 3-core design, improved in terms of EMC characteristics comparing favorably with a 4-core version. The protective conductor PE, divided into 3 is uniformly stranded in the interstices. This enables an extremely concentric structure
  • The minimum cross-section of 0,752 meets the requirements of DIN EN 60204 part 1
  • UV-resistant
  • Outdoor application
  • This screened motor supply cable with the low mutual capacitance of the single cores because of the special PE core insulation and low screen capacitance enable a low-loss transmission of the power compared to PVC-sheathed connecting cables
  • The materials used in manufacture are cadmium-free and contain no silicone and are free from substances harmful to the wetting properties of lacquers

Tests

  • PVC self-extinguishing and flame retardant acc. to DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B).

Application

  • The design of the TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable is suitable for fixed indoor installation and is not suitable for outdoor installation. In indoor conditions, the product can work effectively in dry or wet environments. The TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable provides and connects medium mechanical stresses in a permanent installation.

  • TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable is used in industries such as automotive, motorcycle and food, environmental technology, packaging, and chemical industry.

>>See more: What makes control cables and electric cables distinct?

The TOPFLEX®-EMV-UV-3 PLUS 2YSLCYK-J control cable is manufactured by HELUKABEL. Besides this product line, we also supply 33,000 products, which include control cables and cable accessories to serve many fields. If you need to learn more about this product or need in-depth advice on electrical connection engineering for your project, please contact our engineers for the earliest answer.
