Currently, the agricultural industry has updated many modern technology techniques such as using power cables, control cables, and signals to optimize the production process. In particular, PROFInet Type A cable is a product line with special characteristics that ensure optimal transmission and can be used even in the harshest conditions.

ROFInet Type A belongs to the line of industrial ethernet control cables, which is one of the cables used mainly in industrial communication networks. The characteristic that distinguishes this cable from other industrial ethernet cables is radiation resistance and protective armor. PROFInet Type A has 2 types for different environments, including:

  • Use for peripheral equipment areas in production plants
  • Used for fixed installation, connecting outdoor peripherals

Application of PROFInet Type A cable

At HELUKABEL Vietnam, cable products of the PROFInet Type A type 5e series are resistant to radiation and covered with protective armor for the purpose of fixed installation in industrial networks. Besides, the PROFInet Type A cable ensures optimal transmission characteristics and can be used even under the harshest conditions.

>>Discover more: Different types of Profinet cables in industries

Thanks to the special construction of the PROFInet Type A control cable series with a cross-linked PVC inner sheath/PUR outer sheath is well suited for stationary applications in production areas, while the type with protective armor with PVC inner sheath/PE outer sheath is ideal for areas with corrosion problems.

Applicable standards

  • Principles of PROFInet

  • ISO/IEC 11801 Standard

  • Standard EN 50173

  • Type 5e

PROFInet Type A cable (Fixed installation, indoor 2x2x0.64 mm - Part no. 801195)

Cable structure

Inner conductor diameter: Copper, bare (AWG 22/1)

Core insulation: XLPE ray cross-linking

Core colours: wh, ye, bu, og

Stranding element: Star quad

Shielding 1: Polyester foil over stranded bundle

Inner sheath material: TPR ray cross-linking

Shielding 2: Polyester foil, aluminium-lined

Total shielding: Cu braid, tinned

Armouring: -

Outer sheath material: PUR

Cable external diameter: app. 6,5 mm ± 0,2 mm

Outer sheath colour: Green similar to RAL 6018

Electrical data

Characteristic impedance: 100 Ohm ± 15 ohm at 1 to 100 MHz

Conductor resistance, max.: 62 Ohm/km

Insulation resistance, min.: 0,5 GOhm x km

Loop resistance: 124 Ohm/km max.

Mutual capacitance: 50 nF/km nom.

Test voltage: 2 kV

Technical data

Weight: app. 63 kg/km

bending radius, repeated: 100 mm

Operating temperature range min.: -40°C

Operating temperature range max.: +80°C

Caloric load, approx. value: 0,29 MJ/m

Copper weight: 32,00 kg/km

PROFInet Type A cable (Fixed installation, indoor 2x2x0.64 mm - Part no. 801195)

PROFInet Type A cable (Fixed installation, outdoor 2x2x0.64 mm - Part no. 801650)

Cable structure

Inner conductor diameter: Copper, bare (AWG 22/1)

Core insulation: PE

Core colours: wh, ye, bu, og

Stranding element: Star quad

Shielding 1: Polyester foil over stranded bundle

Inner sheath material: PVC

Shielding 2: Polyester foil, aluminium-lined

Total shielding: Cu braid, tinned

Armouring: Stell band

Outer sheath material: PE

Cable external diameter: app. 9,3 mm ± 0,5 mm

Outer sheath colour: Black

Electrical data

Characteristic impedance: 100 Ohm ± 15 ohm at 1 to 100 MHz

Conductor resistance, max.: 62 Ohm/km

Insulation resistance, min.: 0,5 GOhm x km

Loop resistance: 115 Ohm/km max.

Mutual capacitance: 50 nF/km nom.

Test voltage: 2 kV

Technical data

Weight: app. 124 kg/km

bending radius, repeated: 100 mm

Operating temperature range min.: -40°C

Operating temperature range max.: +70°C

Caloric load, approx. value: 2,14 MJ/m

Copper weight: 31,00 kg/km

HELUKABEL is known as a long-standing German signal and control cable brand since 1978, we provide solutions for control cables, signals, and accessories for machine operation in manufacturing industries. With the orientation of sustainable and long-term development, we always prioritize investment in quality issues, to ensure stability, efficiency, performance, and safety for all products. To get the optimal solutions for your field, contact our specialized engineers for the fastest advice and support!
