What is PROFInet? Top 4 PROFInet cables for industrial networks
PROFInet signal cables are widely used in many industries and play an important role in transmitting signals from machinery and equipment to the control center. Depending on the installation environment and specific requirements, you can choose one of the corresponding PROFInet signal cables.
1. What is Profinet?
Profinet (often abbreviated as PROFInet, as an acronym for Process Field Net) is an industry technical standard for data transmission over industrial Ethernet, designed to collect data from and control equipment in industrial systems, with exceptional strength in delivering data under tight time constraints (on the order of 1 ms or less). This standard is maintained and supported by PROFIBUS & PROFInet International (PI), an organization based in Karlsruhe, Germany.
2. PROFInet type A fixed installation, indoor 2x2x0.64 mm
2.1 Cable structure
- Inner conductor diameter: Copper, bare (AWG 22/1)
- Core insulation: PE
- Core colours: wh, ye, bu, og
- Stranding element: Star quad
- Shielding 1: Polyester foil over stranded bundle
- Inner sheath material: PVC
- Shielding 2: Polyester foil, aluminum-lined
- Total shielding: Cu braid, tinned
- Outer sheath material: PVC
- Cable external diameter: app. 6,5 mm ± 0,2 mm
- Outer sheath colour: Green similar to RAL 6018
2.2 Technical data
- Weight: app. 67 kg/km
- Bending radius, repeated: 65 mm
- Operating temperature range min.: -40°C
- Operating temperature range max.: +80°C
- Caloric load, approx. value: 0,34 MJ/m
- Copper weight: 32,00 kg/km
2.3 Application
HELUKAT® PROFInet Class A Cat 5e has stable and fast signal transmission, used in harsh conditions. These cables are a line of signal cables designed for conventional fixed installations and a PU-sheathed version for fixed installations in harsh industrial environments.
Part no. 800653, PROFInet type A (SK)
Datasheet: HERE
3. PROFInet type B Mobile use 2x2x0,75 (stranded) + 4x1,5qmm
3.1 Cable structure of PROFInet type B
- Inner conductor diameter 1: Copper, bare (AWG 22/7)
- Inner conductor diameter 2: Copper, bare (AWG 16/84)
- Core insulation 1: Foam-skin-PE
- Core insulation 2: PO
- Core colours 1: wh, ye, bu, og
- Core colours 2: Black
- Stranding element 1: Double core
- Shielding 1: Polyester foil over stranded bundle
- Shielding 2: Polyester foil, aluminum-lined
- Total shielding: Polyester foil
- Outer sheath material: FRNC
- Cable external diameter: app. 10,3 mm ± 0,3 mm
- Outer sheath colour: Green similar to RAL 6018
3.3 Technical data PROFInet type B
- Weight: app. 153 kg/km
- bending radius, repeated: 103 mm
- Operating temperature range min.: -40°C
- Operating temperature range max.: +70°C
- Caloric load, approx. value: 1,50 MJ/m
- Copper weight: 94,00 kg/km
3.3 Application
HELUKAT® PROFInet Type B has a versatile application with a core structure consisting of 7 fibers. This power cable corresponds to PROFInet class B with the power supply integrated, which has a flame-retardant and halogen-free construction.
Part no. 801651, PROFInet type B (SK)
Datasheet PROFInet type B
OTHER POSTS >>> 3 THINGS TO KNOW ABOUT HELUDATA® EN-50288-7 SIGNAL CABLES
4. HELUKAT® PROFInet C CAT.5e SF/UTP PUR CHAIN
4.1 Cable structure HELUKAT® PROFInet C
- Inner conductor diameter: Copper, tinned (AWG 22/7)
- Core insulation: Foam-skin-PE
- Core colours: wh, ye, bu, og
- Stranding element: Star quad
- Shielding 1: plastic-coated aluminium foil (St)
- Shielding 2: Cu braid, tinned
- Total shielding: Cu braid, tinned
- Outer sheath material: PUR
- Outer sheath colour: Green
4.2 Technical data HELUKAT® PROFInet C
- Weight: app. 61 kg/km
- Operating temperature range min.: -40°C
- Operating temperature range max.: +80°C
- Caloric load, approx. value: 0,85 MJ/m
- Copper weight: 32,00 kg/km
4.3 Application of HELUKAT® PROFInet C
HELUKAT® PROFInet C CAT.5e SF/UTP PUR CHAIN offers excellent transmission characteristics. These cables correspond to the PROFInet Class C classification for continuous motion and are designed for applications with torsion loads, robotics, etc.
Part no. 800655, PROFInet type C (SK)
Datasheets: HELUKAT® PROFInet C CAT.5e SF/UTP PUR CHAIN
5. HELUKAT® PROFInet R+ CAT.5e SF/UTP PUR ROBOTIC
5.1 Cable structure PROFInet R+ CAT.5e SF/UTP PUR ROBOTIC
- Inner conductor diameter: Copper, tinned (AWG 22/19)
- Core insulation: Foam-skin-PE
- Core colours: wh, ye, bu, og
- Stranding element: Star quad
- Shielding 1: plastic-coated aluminium foil (St)
- Shielding 2: Cu braid, tinned
- Total shielding: Cu braid, tinned
- Outer sheath material: PUR
- Outer sheath colour: Green
5.2 Technical data HELUKAT® PROFInet R
- Weight: app. 63 kg/km
- Operating temperature range min.: -30°C
- Operating temperature range max.: +90°C
- Caloric load, approx. value: 0,55 MJ/m
- Copper weight: 33,00 kg/km
5.3 Application of PROFInet R+ CAT.5e SF/UTP PUR ROBOTIC
PROFInet R+ CAT.5e SF/UTP PUR ROBOTIC offers excellent transmission characteristics. These cables correspond to the PROFInet Class R classification for continuous motion and are designed for applications with torsion loads, robotics, etc.
Part no. 11007800, PROFInet Type R, flame-retardant
Datasheets: PROFInet R+ CAT.5e SF/UTP PUR ROBOTIC
The choice of signal cable will depend on the characteristics of the industry and the installation environment. Thus, ensure the cable transmits the signal transmission stable and instantaneous, serving the remote monitoring process of the business. If you want to choose the best signal and control cables for your demand and purposes, please contact our engineers for advice.
