Applications of JZ-600-Y-CY anti-inteference control cable

Application in multiple fields of JZ-600-Y-CY

Before putting any product into a system, especially control cables, we should know the basic information such as characteristics, applicability, structure, or other information number of each cable line so that the operation will also become much more convenient.

1. The general characteristics of the JZ-600-Y-CY cable

At HELUKABEL, the JZ-600-Y-CY control cable has shielding tape with 1 yellow-green grounded wire. It is different from the previous JZ-600 copper cable line, which does not include shielding tape. The wire is designed with a variety of conductors from 1 to 25 cores with cross-sections from 0.5 mm2 to 185 mm2.

It is resistant to oil vapors, chemical vapors, in addition to UV rays, so it can be used outdoors. Besides, the materials used in the production process are cadmium-free, silicone-free, and free of harmful substances.
>>Find out more: The structure and application of anti-inteference cables

JZ-600-Y-CY cable

2. Environmental conditions

Control cables and connections in machine tools, conveyors, and production lines, for installations in mills, air conditioners, steel mills, and rolling mills. Suitable installation for flexible use for medium mechanical stress with free movement without tensile stress or forced movements in dry or humid room conditions as well as the external environment (with outer sheath) black PVC, especially resistant to UV radiation).

The conductors, when manufactured, are twisted together with a small twist to create the flexibility of the cable. This allows the cable to bend at a small angle, making it easy to work in high, narrow locations and in cable trays. However, it is not suitable to be buried directly in the ground (with a diameter of less than 20 mm) or as an underwater cable.

In addition, shield tape ensures a high degree of screening to optimize EMC (electromagnetic compatibility) features. It is recommended that you contact a large circle of copper braid at both ends. The product complies with the Low Voltage Directive 2006/95/EC.

3. The structure of the control cable JZ-600-Y-CY

  • Copper conductor according to DIN VDE 0295 cl.5, fine wire, BS 6360 cl.5, IEC 60228 cl.5
  • TI2 type special PVC compound magnetic insulation enclosure according to DIN VDE 0207-363-3/DIN EN 50363-3
  • Cores identified according to DIN VDE 0293, consecutively numbered black cores in white
  • With GN-YE ground wire (from 03 cores or more)
  • Cores stranded in layers with optimal lay length
  • PVC inner sheath.
  • Tinned copper braided screen, approx 85% coverage
  • Outer sheath made of special PVC type TM2 according to DIN VDE 0207-363-4-1/ DIN EN 50363-4-1
  • Sheath color: black (RAL 9005)
  • With meter marking
Technical data of JZ-600-Y-CY

4. Technical data

Adapted to DIN VDE 0262 and DIN VDE 0285-525-2-51/ DIN EN 50525-2-51

Temperature range
flexing -15°C to +80°C
fixed installation -40°C to +80°C
Nominal voltageU0/U 0,6/1 kV
Test voltage4000V
Breakdown voltagemin. 8000 V
Insulation resistancemin. 20 MOhm x km
Coupling resistancemax. 250 Ohm/km
Minimum bending radiusflexing 10x cable Ø
fixed installation 5x cable Ø
Radiation resistanceup to 80x106 cJ/kg (up to 80 Mrad)

Through nearly 45 years of developing wire, cable, and accessory technology, we are present in 40 countries and 69 locations. Besides, strenuous efforts are made by our team of more than 2,500 employees, along with the orientation of constantly investing and innovating technology in parallel with the development of modern society.
>>See more: Control cables versus electric cables

If you still have any concerns or questions, don't hesitate to reach out to HELUKABEL Vietnam's engineering team promptly for detailed assistance.
