Three outstanding features of PAAR-TRONIC-CY anti-interference signal cable

PAAR-TRONIC-CY anti-interference signal cable from HELUKABEL is a cable line specifically manufactured for applications that require accurate and stable signal transmission.

PAAR-TRONIC-CY anti-interference signal cable

The PAAR-TRONIC-CY anti-interference signal cable product line is designed by HELUKABEL to ensure flexible use in many applications, highly suitable for use in areas prone to signal interference by cables thanks to a high degree of screening and anti-interference. This significantly reduces the impact of electromagnetic compatibility in parallel wiring. In particular, the copper anti-interference layer is also used as an earthing strap.

The PAAR-TRONIC-CY anti-interference signal cable
The PAAR-TRONIC-CY anti-interference signal cable

1. Technical data of PAAR-TRONIC-CY anti-inteference cable

PVC data cable in alignment with DIN VDE 0812

Temperature rangeflexible -5°C to +80°C
fixed -30°C to +80°C
Peak operating voltage350 V (not for high power current installation purposes)
Test voltage core/core1200 V
Test voltage core/screen800 V
Breakdown voltage2400 V
Mutual capacitance core/coreat 800 Hz
0.14 - 0.25 mm²: approx. 100 pF/m 0.34 - 1.5 mm²: approx. 150 pF/m
Mutual capacitance core/screenat 800 Hz
0.14 mm²: approx. 240 pF/m
0.25 mm²: approx. 270 pF/m
Capacitive coupling k1at 800 Hz, max. 300 pF/100m
Characteristic impedance78 Ohm,
(approx. value)
Inductanceapprox. 0.65 mH/km
Coupling resistanceat 30 MHz, approx. 250 Ohm/ km
Minimum bending radiusflexible 10x Outer-Ø
fixed 5x Outer-Ø

Please refer to the datasheet of PAAR-TRONIC-CY here .

2. Top 3 outstanding features of PAAR-TRONIC-CY anti-interference cable

2.1 Twisted pairs

The inner cable cores of the PAAR-TRONIC-CY are twisted in pairs, which reduces the electromagnetic radiation generated from the two cables themselves. Besides, the signals of the two wires will be in opposite phase, limiting the possibility of signal interference, while also helping to reduce crosstalk between the two pairs of wires and improving the ability to eliminate electromagnetic interference from the outside. The design of twisting the cores together also increases the flexibility of the cores as well as the cable as a whole.

2.2 Optimal lay-length

The cores of PAAR-TRONIC-CY anti-interference signal cable are twisted with an optimal lay-length, helping to increase the anti-interference ability between wires and twisted pairs.

2.3 Tinned drain wire

The design with tin-plated interference conductor brings many positive effects in limiting interference when operating such as:

  • Electromagnetic interference elimination: The drain wire is made from tin-plated copper, which is connected to an anti-interference layer that conducts the interference signals running around the wire to the ground, increasing the cable's resistance to interference.
  • Effective earthing solutions: During machine operation, it is inevitable that residual charges will be generated. This tinned drain wire is also capable as an earthing wire, helping to transmit the residual charges from the device to the ground, ensuring user safety.

>>See more: Features of TRONIC-CY (LiY-CY) cable

In addition, to meet large-sized machinery, you can refer to the PAAR-TRONIC-Li-2YCY anti-interference signal cable.

The PAAR-TRONIC-Li-2YCY anti-interference signal cable for large-sized machinery
The PAAR-TRONIC-Li-2YCY anti-interference signal cable for large-sized machinery

Please refer to the datasheet of PAAR-TRONIC-Li-2YCY here .

With an insulating cover made from exceptionally durable PE plastic, the wire operates effectively for a long time without affecting transmission quality, limiting machine downtime for repeated repair replacement. In addition, this cable line is also suitable for popular connection protocols on the market today such as: RS422, and RS485.

>> See more: Different types of HELUKABEL's signal cables
