3 TYPES OF SUSTAINABLE CONTROL CABLES IN OIL ENVIRONMENTS

Nowadays, it is important to choose cables that are capable of performing well in special environments, often using chemicals, grease, or high temperatures. One of the reasons is that it affects the performance of a whole chain of production and processing systems, especially the output products of enterprises.

Control cables are a special type of cable used to transmit signals and control functions in the system of machinery and equipment to control converters remotely, commonly used in the transmission of data or low voltage signals.

In addition, the control cable also provides power to the control system of the equipment inside the building or is used for industrial control circuits such as in technical systems and equipment, machinery, instrument, meter, air conditioner, etc. Control cables are currently a widely used product line on the market today.

JZ500 - flexible control cable, meter marking

Properties

• Oil-resistant, oil-based chemical resistant

• Compatible with chain systems

• Compatible with torsion condition

• The materials used in the production process do not contain cadmium or silicone and are free of harmful substances.

Application

This cable is suitable for use in flexible applications with moderate mechanical stress and free movement without tensile stress or forced movements in dry, humid, or wet room conditions. However, it is not suitable for outdoor air conditions. These cables are commonly used as measurements in machine tools, conveyors, assembly lines in machinery manufacturing, air conditioning, temperature, steel production, etc.

The selected PVC compounds ensure good flexibility as well as meet commercial requirements and are easy and quick to install. The product complies with the low voltage directive 2006/95/EC.

F-CY-JZ - flexible, Cu-screened, EMC-preferred type, meter marking

Properties

• Anti-interference with tinned copper mesh with 85% coverage

• Oil-resistant, oil-based chemical resistant

• The materials used in the production process do not contain cadmium or silicone and are free of harmful substances.

Application

Flexible cables are used with free movement without tensile stress or forced movement in dry, wet or wet rooms but not in outdoor conditions. These cables are commonly used as data transmission cables in control circuits, in the tool and machine manufacturing industries, and as signal cables in computer and electronic systems. A plastic shield is added between the conductor cores and the tinned copper mesh, which prevents the mesh from damaging the insulation and also makes the overall diameter of the wire smaller, allowing lighter wire and a better bend radius.

This is an ideal interference-free control cable for the above applications. To optimize EMC (electromagnetic compatibility) features, it is recommended that you connect an anti-interference mesh at both ends. The product complies with the low voltage directive 2006/95/EC.

Y-CY-JB - flexible, Cu-screened, transparent, EMC-preferred type, meter marking, and distinguishing cores by color.

Properties

• Anti-interference with the tinned copper braided screen with 85% coverage

• Oil-resistant, oil-based chemical resistant

• The materials used in the production process do not contain cadmium, silicone, or harmful substances that affect the permeability of lacquer.

Application

For use as a data and control cable in machinery, computer systems, etc., as well as a signal cable for electronics. The high level of screening ensures a high degree of interference protection. The screening density assures disturbance-free transmission of all signals and impulses. The PVC-inner sheaths of those cables raise the mechanical stress. The applied clear PVC outer sheath accentuates the optical view of the tinned copper braid. These cables are suitable for flexible use for medium mechanical stresses with free movements. The dense screening assures disturbance-free transmission of all signals and impulses. An ideal disturbance-free control cable for the above application.

These cables are suitable for flexible use for medium mechanical stresses with free movements. It is also an ideal shield control cable for the above application. To optimize EMC features, it is recommended that you connect an anti-interference mesh layer at both ends. The product complies with the Low Voltage Directive 2006/95/EC.

Power cables are gradually taking an important position in today's modernized life, in which technological developments increase exponentially, and equipment and machinery also innovate to operate in the direction of optimizing labor motion. With the criteria to ensure stability, efficiency, high performance, and safety, the power cable products at HELUKABEL have undergone rigorous quality testing stages according to common global standards.
